UV6090

Short Description:

UniPrint UV6090 flatbed printer is the ideal solution for custom printing products, UV printing has wide application on all kinds materials.phone cases, metal(aluminum,copper etc), alloys, mirror, gifts packaging(wood, carbon paper,metal), tablet cover, USB sticks, DVD disc, industry signs, badge, plastic card, PVC, glass, wood, paper etc.

Send email to us

Product Detail

Product Tags

Video

Machine Parameter

Item	UV FLATBED PRINTER
Model	UV6090
Nozzle Configuration	Epson DX7 or Epson i3200
Max print size	600mm*900mm
Print height	10cm or can be customized
Print speed DX7	Production 4m2/H; High quality 3.5m2/H
Print speed i3200	Production 10m2/H; High quality 8m2/H
Print resolution	720360dpi 720720dpi 7201080dpi 7201440dpi
Print material Type:	Acrylic, Aluminum, Ceramic, Foam board, Metal, Glass, Cardboard, Leather, Phone case and other flat objects
Ink Color	4Color（C、M、Y、K) ; 5Color（C、M、Y、K、W)
Ink type	UV ink. Solvent ink, Textile ink
Ink Supply System	Continuous Ink Supply System
UV Curing System	LED UV Lamp / Water cooling system
Rip software	RiPrint, Maintop 6.0 standard/ Photoprint optional
Image format	TIFF,JPEG,EPS,PDF etc
Voltage	AC220V 50-60HZ
Power supply	700W
Data interface	3.0 high speed USB interface
Operation System	Microsoft Windows7/10
Operating environment	Temperature: 20-35℃ ; Humidity: 60%-80%
Machine size	16001700700mm /200kg
Packing size	170018001000mm /300kg
Packing way	Wooden package (plywood export standard)

UV Flatbed Printer Advantages

1. EPSON PRINTHEAD DX7 or i3200 OPTIONAL
2. HIGH RESOLUTION PRINTING
3. LARGE PRINTING SIZE 60CM*90CM, MIDDLE SIZE 1313, 1316 OR LARGE SIZE 2513 2030 AVAILABLE.
4. CMYK+White or CMYK+White+Varnish
5. APPLY TO ALL KINDS FLAT MATERIALS LIKE GLASS, ACRYLIC, WOOD, PVC BOARDS ETC
6. UV BASE INK. CAN BE CURED IMMEDIATELY. WITH BULK INK SUPPLY SYSTEM. SUPPORT TO LARGE PRINTING PRODUCTION TASKS CONTINOUSLY
